Sensor

1/2.8", 2 megapixel, progressive scan, CMOS

Lens

2.8mm@ F1.8; Angle of View (H): 108°

Shutter

Auto/Manual, 1/6~1/8000 s

Day/Night

IR-cut filter with auto switch (ICR)

Min. Illumination

Colour: 0.06 Lux (F1.8, 50IRE)

Black & White: 0.03 Lux (F1.8, 50IRE)

S/N

>52dB

Image Rotation

Supported

Max. Resolution

1920×1080

Video Compression

H.264,MJPEG

Frame Rate

1080P (1920×1080): Max.30 fps; 720P (1280×720): Max. 30 fps; D1 (720×576): Max. 25 fps

ROI

Supported

Video Streaming

Triple

OSD

Up to 8 OSDs

Privacy Mask

Up to 4 areas

Audio Compression

G.711

Two-way audio

Supported

Protocols

L2TP,IPv4,IGMP,ICMP,ARP,TCP,UDP,DHCP,PPPoE,RTP,RTSP,Qos,NTP,FTP,HTTP,SNMP,SIP

Compatible Integration

ONVIF, IMOS,API

Audio I/O

Audio cable

Input: impedance 35 kΩ; amplitude 2 V [p-p]

Output: impedance 600 Ω; amplitude 2 V [p-p]

alarm I/O

1 / 1

Network

10M/100M Base-TX Ethernet

Power

12 V DC, or PoE (IEEE802.3 af)

Power consumption: 3.5W (5.5W with IR on)

Dimensions (Ø x H)

Φ109 x 81 mm (Ø4.3” x 3.2”)

Weight

0.45 kg (1.0 lb)

Working Environment

-35°C ~ +60°C (-31°F ~ 140°F), Humidity ≤ 90% RH(non-condensing)

Vandal Resistant

IK10

Ingress Protection

IP66
