Sensor

1/2.8", 2 megapixel, progressive scan, CMOS

Lens

[email protected];

Angle of view(H): 80.5°

Shutter

Auto/Manual, 1/6~1/8000 s

Day/Night

IR-cut filter with auto switch (ICR)

IR

30m (98 ft) IR range

AWB(Auto white balance)

Auto/manual

Gain Control

Auto/manual

Image Rotation

Supported

WDR

Digital

Noise Reduction

2D/3D

Max. Resolution

1920×1080

Video Compression

H.264/MJPEG

Frame Rate

1080P (1920×1080): Max. 30 fps; 720P (1280×720): Max. 30 fps; D1 (720×576): Max. 25 fps

Video Streaming

Triple

OSD

Up to 8 OSDs

9:16 Corridor Format

Supported

Motion Detection

Up to 2 areas

Privacy Mask

Up to 4 areas

Protocols

IPv4,IGMP,ICMP,ARP,TCP,UDP,DHCP,RTP,RTSP,Qos,DNS,DDNS,NTP,FTP,UPnP,HTTP

Compatible Integration

ONVIF

Network

10M/100M Base-TX Ethernet

Power

12 V DC, or PoE (IEEE802.3 af)

Power consumption: 3.5W (5.5W with IR on)

Dimensions (Ø x H)

Φ126 x 94 mm (Ø5.0” x 3.7”)

Weight

0.33 kg (0.73 lb)

Working Environment

-35°C ~ +60°C (-31°F ~ 140°F), Humidity ≤ 90% RH(non-condensing)

Ingress Protection

IP66
